PC923

OPTOISO 5KV GATE DRIVER 8DIP,

Family    Isolators - Gate Drivers
Series    OPIC™
Packaging      Tube
Technology    Optical Coupling
Number of Channels    1
Voltage - Isolation    5000Vrms
Common Mode Transient Immunity (Min)    1.5kV/µs
Propagation Delay tpLH / tpHL (Max)    500ns, 500ns
Pulse Width Distortion (Max)    -
Rise / Fall Time (Typ)    200ns, 200ns
Current - Output High, Low    -
Current - Peak Output    400mA
Voltage - Forward (Vf) (Typ)    1.6V
Current - DC Forward (If) (Max)    20mA
Voltage - Supply    15 V ~ 30 V
Mounting Type    Through Hole
 Package    8-DIP
