YL303H-S-5VDC

Giá: 5.000₫ Còn hàng

Category Relays Family Power, Over 2 Amps Relay

Category Relays
Family Power, Over 2 Amps

Relay Type General Purpose
Coil Type Non Latching
Coil Current 30mA
Coil Voltage 5VDC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 7A
Switching Voltage 250VAC, 100VDC - Max
Turn On Voltage (Max) 4.7 VDC
Turn Off Voltage (Min) 1.2 VDC
Features Sealed - Fully
Mounting Type Through Hole
Termination Style PC Pin
Packaging Bulk
Contact Material Silver Tin Oxide (AgSnO)
Operate Time 10ms
Release Time 10ms
Coil Power 360 mW
Coil Resistance 400 Ohms
Operating Temperature -40°C ~ 70°C
