ZXMN3A14FTA
Giá: 1.700₫ Còn hàng
MOSFET N-CH 30V 3.2A SOT23-3
MOSFET N-CH 30V 3.2A SOT23-3,
FETs - Single
Packaging Tape & Reel
FET Type MOSFET N-Channel, Metal Oxide
FET Feature Logic Level Gate
Drain to Source Voltage (Vdss) 30V
Current - Continuous Drain (Id) @ 25°C 3.2A (Ta)
Rds On (Max) @ Id, Vgs 65 mOhm @ 3.2A, 10V
Vgs(th) (Max) @ Id 1V @ 250µA
Gate Charge (Qg) @ Vgs 8.6nC @ 10V
Input Capacitance (Ciss) @ Vds 448pF @ 15V
Power - Max 1W
Mounting Type Surface Mount
Package / SOT-23-3
