6DOF MPU 6500 Sensor 6-axis

Giá: 60.000₫ Còn hàng

GY-6500 MPU-6500 6DOF six-axis accelerometer 6-axis attitude gyro sensor module SPI Interface

GY-6500 MPU-6500 6DOF six-axis accelerometer 6-axis attitude gyro sensor module SPI Interface
MPU-6500 modules (three-axis gyroscope + triaxial accelerometer)
Module Model: GY-6500
Use Chip: MPU-6500
Power supply :3-5v (internal low dropout regulator)
Communication: Standard IIC / SPI communication protocol
Chip 16bit AD converter, the output data 16
Gyro range: ± 250 500 1000 2000 ° / s
Acceleration range: ± 2 ± 4 ± 8 ± 16g
Using Immersion Gold PCB, machine welding process to ensure quality
2.54mm pin pitch
Module size 15mm * 25mm

Ứng dụng sản phẩm
