MBI5167

Giá: 6.500₫ Còn hàng

8-Channel Constant Current LED Sink Driver

8-Channel Constant Current LED Sink Driver,

Output Channel    8
Max. Sustaining Voltage    17V
Constant Output Current Per Channel    3~45mA @ 5V supply voltage; 3~30mA @ 3.3V supply voltage
Max. Clock Frequency    25MHz
Output Current Accuracy-between channels    <±3% (max.)
Output Current Accuracy-between ICs    <±6% (max.)
Supply Voltage    3.0~5.5V
Constant Output Current Invariant to Load Voltage Change    YES
Adjusted Output Current    through an external resistor
Schmitt Trigger Input    YES
Staggered Delay of Output    YES
RoHS Compliant Package    SOP16

   data sheet



Ứng dụng sản phẩm
