Wireless hot products copy control 433 frequency wireless remote control
Main Technical Parameter
Frequency: 433.92 mhz
Copy code :12f629 ic ; 12f683 ic
Encoding Chip: 2262, 2264, 2260, EV1527, HCS301, HCS300, etc.
Learning code, Fixed code, Rolling code.
Button image: ABCD,1234,Lock/Unlock/Mute/Light Optional/
Led light color: Standard Blue
Other Yellow, Red, Green,Purple etc. can be optional.
1). Erase the code (Delete the original code)
A.Press button "A" C and "B" at the same time until LED flash 3 times
B.Release button "B" and Keep pressing button "A" , then press button "B" 3 times,LED flash fast
C.Release button "A" C,finish code clearance
2). Duplicating (Copy code from original transmitter)
A. Put duplicator aside of original transmitter,as close as possible.
B. Press and hold button "A" of original transmitter,then press and hold button "A" of duplicator until you see the duplicator's LED flash and keep lighting
C. Release both buttons,finish code copy,copy other buttons in same way.
Press and hold button "C" and "D" for 3 seconds, the LED flash, all buttons return back to the latest copy codes.
Transmission distance: 50-80meters (open space)
